FUTABA FX-36 - Page 109

109
＜ Linkagemenu ＞
Taphereandgotothe
Servo2settingspage.
(Displayandsettings
contentisthesameas
Servo1.)
WhentheAlarmor
Vibratoroptionsare
activated,theservo
connectionwill
display.
*ThisalarmanddisplayislimitedtotheS.BUS
servosconnectedtotheservosensors.
Tappingthiswill
takeyoutothe
settingsscreenfor
thecurrentalarm
Telemetry:Servosensor[Current]
The SBS-01S can monitor and display the
in-flight current, operating angle, and internal
temperature of up to two S.BUS2 servos.
If you forget to connect the servo wiring during
fuselage assembly, or the servo was disconnected,
an alarm can be activated at the transmitter.
*Servosensormustbeinstalledintheaircraft.
ŏ Select [Servo sensor] in the Telemetry
screen and access the setup screen
shown below.
Max.andmin.values
sincethepower
wasturnedONwill
display.
Setsthecurrenton
whichthealarm
operates.
Alarmischosenfrom
Buzzer,Voice,and
Inhibit.
AllowsSpeechtobe
turnedONorOFF.
Vibratorischoicesare
type1-3,andInhibit.
↑Anupwardarrow
indicatesthealarm
willsoundwhenthe
currentreachesabove
yoursetvalue.
↓Adownwardarrow
indicatesthealarm
willsoundwhenthe
currentreachesbelow
yoursetvalue.
Initialvalue:↑ 10.0A↓ 0.0A
Adjustmentrange0.0A~10.0A
( ↑ Limit≧↓ Limit)
ŏReturn to Linkage menu
Tappingthisandselecting
"Buzzer"willcausethedevice
tosoundanalarmwhen
servosarenotconnected.
Tappingthisandselecting
"Eachtype"willcausethe
devicetovibratewhenservos
arenotconnected.
