＜ Linkagemenu ＞
Altitude
Setsthealtitude
onwhichthealarm
operates.
↑ Anupwardarrow
indicatesthealarm
willsoundwhenthe
altitudereachesabove
yoursetvalue.
↓ Adownwardarrow
indicatesthealarm
willsoundwhenthe
altitudereachesbelow
yoursetvalue.
Alarmischosenfrom
Buzzer,Voice,and
Inhibit.
AllowsSpeechtobe
turnedONorOFF.
AllowsMelodytobe
turnedONorOFF.
ŏ Tap the [Altitude] button in the Telemetry screen to
call the setup screen shown below.
Max.andmin.values
sincethepower
wasturnedONwill
display.
*It cannot be used in FASST mode and S-FHSS mode.
*Only receiver voltage and EXT voltage can be used in
FASSTest12CH mode.
*The FASSTest18CH /T-FHSS mode can use all the telemetry
functions.
Type1
Type2
Type3
"Vibrator"type
Ifthefollowingtypesareselected,thetransmitter
willvibrateduringthewarning.
Telemetry:Altitude
Displaying data from the altitude
Altitude is a screen which displays / sets up the altitude
information from an optional altitude sensor or GPS sensor.
The altitude of the model which is Àying can be known. If it
becomes higher (low) than preset altitude, you can be told by
alarm. Warning by vibration can also be chosen. Data when
a power supply is turned on shall be 0 m, and it displays the
altitude which changed from there. Even if the altitude of an
air¿eld is high, that shall be 0 m and the altitude difference
from an airfield is displayed. This sensor calculates the
altitude from atmospheric pressure. Atmospheric pressure
will get lower as you go up in altitude. Using this, the
sensor will estimate the altitude. Please understand that an
exact advanced display cannot be performed if atmospheric
pressure changes in a weather situation.
First, the set of a reference is required.
1. The model and transmitter to which the
altitude sensor was connected are turned on.
2. Tap to the [Preset] of "Reference" item.
*Atmospheric pressure is changed according to the weather
also at the same air¿eld. You should preset before a Àight.
Alarm set : Altitude
1. Tap Alarm and choose from Bu]]er, Voice,
and Inhibit.
2. Choose "Inhibit" for Vibrator if no
t
using the
vibrator alarm. If using vibrator, choose one
of the three types.
3. Tap to the Limit [xxx
m
] item .
4. Adjust the rate using the "ʈʈ" "ʈ" "ʆ" "ʆʆ"
buttons.
Initial value: Ń200m Ņ-50m
Adjustment range -500m~+3,000m
(ŃLimit
≧
ŅLimit)
*When the screen is tapped for one second, the rate is reset
to the initial value.
5. To terminate the input and return to the
original state, push the H/E button.
*AnaltitudesensororGPSsensormustbeinstalledintheaircraft.
● IfthisissettoMode1-4,
ariseanddivearetold
byadifferentmelody.
Mode1:Littlerise/dive
→ Melodychanges
:sensitively
Mode4:Bigrise/dive
→ Melodychanges
:insensible
ŏReturn to
Linkage menu
