32
4.1.6 Channel 6 - Switch on / off the lamp, reset, speed control of cooling fan
0 Open, max. speed of fan
127 Open, min. speed of fan (silent operation) from 0 to 127
- decreasing speed of fan
128 - 139 Switch on the lamp, reset, open position
140 - 239 No function
230 - 239 Switch off the lamp after 3 seconds
240 - 255 No function
4.1.7 Channel 7 - Colours
Linear colour change following the movement of the slider. In this way you can stop the colour-wheel in any
position - also between two colours creating double-coloured beams.
Between 128 and 190 and between 193 and 255, the colour-wheel rotates continuously the so-called "Rainbow"
effect.
0 Open / white
10 Turquoise
21 Red
32 Cyan
42 Green
53 Magenta
64 Light Blue
74 Yellow
85 Green
96 Pink
106 Blue
117 Orange
128 - 190 Forwards rainbow effect from fast to slow
191 - 192 No rotation
193 - 255 Backwards rainbow effect from slow to fast
4.1.8 Channel 8 - No function
4.1.9 Channel 9 - Prism-wheel
0 - 95 Open position (hole)
96 - 159 3 - facet rotating prism
160 - 255 Prism/Gobo macros
160 - 167 Macro 1
168 - 175 Macro 2
176 - 183 Macro 3
184 - 191 Macro 4
192 - 199 Macro 5
200 - 207 Macro 6
208 - 215 Macro 7
216 - 223 Macro 8
224 - 231 Macro 9
232 - 239 Macro 10
240 - 247 Macro 11
248 - 255 Macro 12
4.1.10 Channel 10 - 3-facet-prism rotation control
0 No rotation
1 - 126 Forwards rotation from fast to slow
127 - 128 No rotation
129 - 255 Backwards rotation from slow to fast
