40
SnEr
This message appears if the lamp lighting sensor is failed. Please contact your dealer.
PoEr
This message will appear if the fixture was shortly disconnect from the mains.
FrEr
This message will appear if the frequency of the mains is not standard 50 or 60 Hz.
9. Technical Specifications
Power supply:
EU-model: 210/230/250 V, 50/60 Hz
US-model: 100/120/210/230/250 V, 50/60 Hz
Power consumption: 400 W
Fuse: T3.15 A
Lamp:
MSD/HSD 230 V/250 W GY-9.5 or MSD/HSD 230 V/200 W GY-9.5
Optical System
-H
igh luminous-efficiency parabolic mirror and double condenser system
-Standard 15° focused beam angle
-Optional 12° and 18° lens
-All lenses are anti-reflection coated
Colours
- 11 interchangeable dichroic-filters plus white
- Colour-wheel with variable rotation speed
Rotating gobos
- 4 metal gobos, 1 glass gobos and 1 dichroic gobo rotating in both directions at different speeds
- Gobo indexing
- Rotating gobo-wheel cont. rotation
- Outside diameter 27 mm, image diameter 23 mm.
Strobe
- Strobe effect with variable speed (1 - 10 flashes per second)
Dimmer
- Smooth dimmer from 0 - 100 %
Prism
- 3-facet-prism rotating in both directions at different speeds
Focus
- Motorized focus from near to far
Motor
- 10 high quality stepping-motors controlled by microprocessors
Electronics
- Digital serial input DMX-512
- 16 control-channels (full 16 bit protocol):
Channel 1: Horizontal mirror-movement 8 bit
Channel 2: Vertical mirror-movement 8 bit
Channel 3: Fine Horizontal mirror-movement 16 bit
Channel 4: Fine Vertical mirror-movement 16 bit
Channel 5: Pan/Tilt speed
Channel 6: Fan speed, On/Off lamp, reset
Channel 7: Colours
Channel 8: No function
Channel 9: Prism-wheel
Channel 10: Prism-rotation
Channel 11: Rotating gobos
Channel 12: Gobo rotation, gobo indexing
Channel 13: No function
Channel 14: Focus
Channel 15: Shutter, strobe
