29
The MH - 660 can be placed directly on the stage
floor or rigged in any orientation on a truss without
altering its operation characteristics (see the
drawing).
The fixture’s base enables to be mounted in two
ways. Use the clamps with screws M10 or M8 -
check the base bottom.
Install a safety-rope that can hold at least 10
times the weight of the fixture. Never use the
carrying handles for secondary attachment.
3.3 Connection to the mains
Connect the fixture to the mains with the power-plug.
The occupation of the connection-cables is as follows:
Safety-rope
Clamp
Connections Possible designations
Cable Pin International US UK
Brown Live L Yellow or brass Red
Blue Neutral N Silver Black
Yell./Green Earth Green Green
