39
DMX Calibration protocol:
After having calibrated required functions press [Enter] to confirm (or [Mode] to cancel and return to the menu
without reset by the "ArES" function) and use the "ArES" function in order to write the calibration values to the
memory (EEPROM) and to make a reset in order to check the new adjusted positions of the colour, effect and rot.
gobo wheels and gobo indexing.
8. Error and Information messages
HEAt
This message appears if you try to switch on the lamp within 5 minutes after having switched it off (the lamp is too
hot). The message will appear on the display if the lamp doesn't ignite within 28 seconds. The MH-660 will store
this information and automatically ignite the lamp when the 5 minutes period has expired.
LAEr
The ignition of the lamp is seven times unsuccessful (the HEAt message appeared six times before), and the
display shows "LAEr", meaning that the lamp could be damaged or even missed, the fixture is overheating (this
can occur if the ambient temperature is 45° C or more) or there could be a failure on the ignitor or ballast.
Please place or replace the lamp, check the ambient temperature or contact your dealer if the situation was not
caused by the lamp.
MbEr
This messsage informs you that the main PCB does not communicate correctly with the Control Board.
CoEr
(color-wheel error) This messsage will appear after the reset of the fixture if the magnetic-indexing circuit malfunctions
(sensor failed or magnet missing) or the stepping-motor is defective (or its driver circuit on the main PCB). The
color-wheel is not located in the default position after the reset.
rGEr
(rotating gobo-wheel error) This message will appear after the reset of the fixture if the magnetic-indexing circuit
malfunctions (sensor failed or magnet missing) or the stepping-motor is defective (or its driver circuit on the main
PCB). The rotating gobo-wheel is not located in the default position after the reset.
IGEr
(rotating gobo indexing error) This message will appear after the reset of the fixture and if the magnetic-indexing
circuit malfunctions (sensor failed or magnet missing) or the stepping-motor is defective (or its driver circuit on the
main PCB). The rotating gobo is not located in the default position after the reset.
EFEr
(prism-wheel error) This message will appear after the reset of the fixture if the magnetic-indexing circuit malfunctions
(sensor failed or magnet missing) or the stepping-motor is defective (or its driver circuit on the main PCB). The
prism-wheel is not located in the default position after the reset.
FtEr
This error message informs you that the fixture was overheating (occured if the ambient temperature is 45° C or
more) and that the relay switched off the lamp. This message will appear on the display until the temperature will
be on a suitable level, then the display will show the HEAt message meaning the lamp is too hot (explanation see
above).
DMX
Channel
123 4 5678
Function COL. - EFEC. RGOB GROT - COLOURS -
CALIBRATION
0 - 255
-
CALIBRATION
0 - 255
CALIBRATION
0 - 255
CALIBRATION
0 - 255
-
STANDARD
PROTOCOL
-
SMOOTH MICROSTEP MOVEMENT
9 10111213141516
EFFECT
(PRISM)
PRISM
ROTATION
ROTATING
GOBOS
GOBO
ROTATION
- FOCUS STROBO DIMMER
STANDARD
PROTOCOL
STANDARD
PROTOCOL
STANDARD
PROTOCOL
STANDARD
PROTOCOL
-
STANDARD
PROTOCOL
STANDARD
PROTOCOL
STANDARD
PROTOCOL
