4 T-STYLE ARM RESTS ADJUSTABLE
540 –UM 1024402 REV08 10/2013 16 Capella / Capella 45
4 T-Style Arm Rests Height Adjustable
Adjusting T-Style Arm Height [Figure 3]
1. Pull out the height adjustment latch lever to
disengage the holding pin.
2. Lift armrest until desired position is acquired (ranges
from 9’’– 13” in ½” increments).
3. Release the height adjustment latch lever to engage
the holding pin.
4. Repeat this procedure for the opposite T-style arm
assembly.
