1. The Capella seat depth is adjusted from the rear of the
wheelchair. It has 3 different depths of seat rail which
come with the standard configuration. The depth of the
seat rails are 15”-16”, 17”-18”, and 19”-20”. Remove
four (4) 1/4-20 x 2” flat head screws (‘A’) and four(4) 1/4-
20 nuts(‘B’) from the bottom side of the back cane
bracket(‘C’).
2. Move the stroller handle assembly (‘D’) backwards 1”
(for example if one wants to change the depth from 15”
to 16”) towards the back of the chair and re-insert the
four (4) 1/-4-20 x 2” flat head screws and four (4) 1/4-20
nuts into the ‘new’ holes. Tighten the screws and nuts
and check the stability of the stroller handle assembly.
3. As the depth of the chair increases or decreases the
horizontal location of the wheel
4. must also change. (Refer Changing Horizontal Location
of Rear Wheels).
5. If one would like to change the depth of the wheelchair
from 15”-16” to 19”-20” then the seat rails need to be
replaced.
