cleaning paper clean head of QBH dust and other dirt! Must ensure that the QBH
head clean pollution-free, then can insert cutting head in the expanded beam!
Adjust the cutting head of coaxial and focus of the lens, then try to cut!
Caution:Install fiber must demand trained professionals to
install fiber, it is forbidden to non-specialists plug QBH!
Lens using considerations
Focusing mirror, protection glasses, QBH head optical surface,
do not use hand touch directly, causing the mirror so easily
scratch or corrosion. If there is grease or dust on the mirror, will
seriously affect the use of the lens, should be timely to clean the
lens.
1. Optical surface strictly prohibited water, detergent and other cleaning. Lens
surface coated a layer of special membrane, if use these to clean the lens will
damage the surface of the lens.
2. Do not place the lens in damp places, this will make the lens surface aging.
3. The lens surface must be clean, if stained with dust, dirt, or water vapor, easy
absorption laser lens coating damage; Light affects the quality of the laser beam,
or a laser beam does not travel through or reflected.
4. When installation or replacement mirror or focus lens, do not use too much
pressure, otherwise it will cause deformation of the lens, thus affect the quality of
the beam.
4.4 Fiber Special Cutting Head
The cutting head is composed of the following parts. Please refer Picture4-11
Note: In view of the cutting head may be modified, with its own independent
specification shall prevail, this manual is only for reference.
4.4.1Fixing of cutting head
Installation: set the laser head onto the machine, there are 4 M6x1(depth
14mm) screws on the back of laser head to fix on the machine. You can
precise locate the position of laser head by the two pin holes on the back, and
so the installation position can be copied. (Please refer Picture 4-12)
4.4.2 Height controller connection
1. Plug the wire into the joint.(Picture4-13)
2. Tighten the blots and nuts.(Picture4-14)
