GALaxy eHydro Elevator Controller Section 6 – Main CPU Faults & Detailed Faults
6-111
Front SD (FSd): Front Slowdown Flags
Bit 0: (UC) Up Hall Call Slowdown
Bit 8: (IU) IR Up Hall Call Slowdown
Bit 1: (DC) Down Hall Call Slowdown
Bit 9: (ID) IR Down Hall Call Slowdown
Bit 2: (CC) Car Call Slowdown
Bit 10:
Bit 3:
Bit 11:
Bit 4: (UD) Up Call Door Open Request
Bit 12:
Bit 5: (DD) Down Call Door Open Request
Bit 13:
Bit 6: (CD) Car Call Door Open Request
Bit 14:
Bit 7:
Bit 15:
Rear SD (RSd): Rear Slowdown Flags
Bit 0: (UC) Up Hall Call Slowdown
Bit 8: (IU) IR Up Hall Call Slowdown
Bit 1: (DC) Down Hall Call Slowdown
Bit 9: (ID) IR Down Hall Call Slowdown
Bit 2: (CC) Car Call Slowdown
Bit 10:
Bit 3:
Bit 11:
Bit 4: (UD) Up Call Door Open Request
Bit 12:
Bit 5: (DD) Down Call Door Open Request
Bit 13:
Bit 6: (CD) Car Call Door Open Request
Bit 14:
Bit 7:
Bit 15:
Motion Tmr: Motion Timer – Timer while the car is in or attempting motion. 100 msec
PAL Stat: Safety PAL Status
Bit 0: PAL Fault
Bit 4: NTS Speed >= 75 fpm
Bit 1: Test Mode Jumper
Bit 5: NTS Speed >= 150 fpm
Bit 2: Rear Door Jumper
Bit 6: NTS Selector OK
Bit 3: NTS Fault
Bit 7: NTS Door Zone
Inspect Svc: Inspection Service
0 = Invalid Inspection Input
1 = Car Top Inspection
2 = Machine Room Inspection
3 = Access Inspection
4 = In-Car Inspection
5 = Car Top Inspection Lock Bypass
6 = Car Top Inspection Gate Bypass
7 = Car Top Inspection Gate and Lock Bypass
% Load: Percent Load Calculated load value from the load weigher
