GALaxy eHydro Elevator Controller Section 4 - Troubleshooting
4-11
Table 4-1: Main CPU Inputs & Outputs
Name
Description
TSTM
Test Mode Jumper
UDA
Up Direction Arrow Output
UL or ULc
Up Level Position from Main CPU position reference
ULO or ULcO
Up Level Output LED from Main CPU
UN
Up Normal Limit NTS Processor Output
UNi
Up Normal Limit Input from NTS Processor Output
UN-1 or UNc
Up Normal Output from Main CPU position reference
UT
Up Terminal Limit NTS Processor Output
UTi
Up Terminal Limit Input from NTS Processor Output
UT-1 or UTc
Up Terminal Slowdown Output from Main CPU position reference
4.9 NTS Processor Inputs and Outputs
Table 4-2: NTS Processor Inputs & Outputs
Name
Description
DL
Down Level Position (internal)
DN
Down Normal Limit Output
DNo
Down Normal Output (internal)
DT
Down Terminal Slowdown Limit Output
DTo
Down Terminal Slowdown Output (internal)
DZ
Door Zone Position Output
DZA
Door Zone Auxiliary (internal)
DZC
Door Zone Clip Output
DZo
Door Zone Output (internal)
SOK
Selector Okay Output
TST
Test Mode Input Jumper
UL
Up Level Position (internal)
UN
Up Normal Limit Output
UNo
Up Normal Output (internal)
UT
Up Terminal Slowdown Limit Output
UTo
Up Terminal Slowdown Output (internal)
