GALaxy eHydro Elevator Controller Section 4 - Troubleshooting
4-10
Table 4-1: Main CPU Inputs & Outputs
Name
Description
NUD
Door Nudging Output
NUDR
Door Nudging Rear Output
OVL
Overload Input
P1-Pn
1ST – Nth Discrete Floor Position Indicator Outputs
PALF
Safety PAL Fault
PS
Pit Switch Input
RDOOR
Rear Door Jumper
RGS
Rear Car Gate Switch Input.
RGS-1
Rear Car Gate Switch Secondary Input
RLM
Rear Lock Middle Input.
RLM-1
Rear Lock Middle Secondary Input
RPM
Rear Door Protection Monitor
RST
Reset Drive Output
RTL
Return to lobby Input
RUN
Run Output Relay Control
RUNi
Run Input
S10
Run Control 120 VAC
S10
Controller Power Input
SD
Solenoid Down Run Output
SDF
Solenoid Down Fast Output
SDFi
Solenoid Down Fast Input
SDi
Solenoid Down Run Input
SE
Safety Edge Input
SELCM
Selector Com COP LED Output
SELOK
Selector Okay
SER
Safety Edge Rear Input
SP150
Speed Greater than 150 fpm
SP75
Speed Greater than 75 fpm
SPD
Motor Up to Speed
STE
Soft-Starter Enable
SU
Solenoid Up Output
SUF
Solenoid Up Fast Output
SUFi
Solenoid Up Fast Input
SUi
Solenoid Up Input
TAD
Top Access Down Input.
TAU
Top Access Up Input.
TF
Top Final Input
TPH
Oil Temperature High
TPL
Oil Temperature Low
TPL
Temp Low Input (Hydraulic Elevators)
TSD
Terminal Speed Device
