GALaxy eHydro Elevator Controller Section 4 - Troubleshooting
4-7
Table 4-1: Main CPU Inputs & Outputs
Name
Description
CDL
Cab Down Lantern Output
COL
Counter Weight Collision Switch Input (Traction Elevators)
CS
In Car Stop Switch Input
CSPI1-3
Car Spare Input 1 – 3
CSPO1-3
Car Spare Output 1 – 3
CSS
Car Safety String Input
CST
Car Stop Switch Input
CTA
Car Top Automatic Input
INS
Car Top Inspection Input
CTS
Car Top Stop Switch Input
CUL
Cab Up Lantern Output
DC
Door Close Output
DCB
Door Close Button Input
DCBR
Door Close Button Rear Input
DCC
DAC Clear Output
DCL
Door Close Limit Input
DCLR
Door Close Limit Rear Input
DCR
Door Close Rear Output
DDA
Down Direction Arrow Output
DET
Detector Edge Input
DETR
Rear Detector Edge Input
DL or DLc
Down Level Position from Main CPU position reference
DLB
Door Lock Bottom Input.
DLB-1
Door Lock Bottom Secondary Input
DLM
Door Lock Middle Input
DLM-1
Door Lock Middle Secondary Input
DLO or DLcO
Down Level Output LED from Main CPU
DLT
Door Lock Top Input
DLT-1
Door Lock Top Secondary Input
DN
Down Normal Limit NTS Processor Output
DNi
Down Normal Limit Input from NTS Processor Output
DN-1 or DNc
Down Normal Output from Main CPU position reference
DO
Door Open Output
DOB
Door Open Button Input
DOBR
Door Open Button Rear Input
DOL
Door Open Limit Input
DOLR
Door Open Limit Rear Input
DOR
Door Open Rear Output
DPM
Door Protect Monitor Input
DT
Down Terminal Limit NTS Processor Output
DTi
Down Terminal Limit Input from NTS Processor Output
