GALaxy eHydro Elevator Controller Section 5 – LCD Interface
5-6
Table 5-5: STATUSF: Control Status Flag (Pops up over current fault)
Bit 0: (sfS10) NO S10 power
Bit 17:
Bit 1: (sfHC) NO HC power
Bit 18:
Bit 2: (sfSS) NO SS input
Bit 19:
Bit 3:
Bit 20:
Bit 4:
Bit 21: (sfSHD) Shutdown (too many run attempts
Bit 5: (sfIO) I/O error during redundancy check
with faults)
Bit 6: (sfINS) Inspection or lock bypass fault
Bit 22: (sfAST) Annual Safety Test
Bit 7: (sfBPI) Binary Position Input Error
Bit 23: (sfSAF) Waiting for Safe (Door Locks and
Bit 8: (sfPOS) Position Error
Gate)
Bit 9: (sfAD) No automatic Doors
Bit 24: (sfTLM) UT or DT limit error
Bit 10: (sfSTP) Stop switch open
Bit 25:
Bit 11: (sfDZ) Door Zone fault
Bit 26: (sfDZF) UL, DL and DZ off at floor
Bit 12: (sfGDL) Gate or Door lock fault
Bit 27:
Bit 13:
Bit 28: (sfFST) Fire Fighter Stop Switch
Bit 14: (sfDCL)No DCL
Bit 29: (sfSEL) Selector Can error
Bit 15: (sfDCC) No Door Close Contact
Bit 30: (sfUDL) UL or DL fault
Bit 16:
Bit 31: (sfLEV) Leveling fault
Table 5-6: STATUSF2: Control Status Flag (Pops up over current fault)
Bit 0: (sfHWI) Hardware Init fault
Bit 16:
Bit 1: (sfFDC) Front Door Closing Fault
Bit 17: (sfIOT) IO Test in progress
Bit 2: (sfRDC) Rear Door Closing Fault
Bit 18:
Bit 3: (sfLVF) Line Voltage Fault
Bit 19:
Bit 4: (sfDVF) Door Voltage Fault
Bit 20: (sfNIT) Non Interference timer
Bit 5:
Bit 21: (sfDRQ) Door open request
Bit 6: (sfDMO) Door motor overload
Bit 22: (sfDPM) Waiting for DPM
Bit 7: (sfHWL) Learn Hoistway Fault
Bit 23: (sfRPM) Waiting for RPM
Bit 8:
Bit 24: (sfVSC) Viscosity operation
Bit 9:
Bit 25: (sfLVR) Leveling request
Bit 10:
Bit 26:
Bit 11: (sfAFS) At Floor Shutdown
Bit 27:
Bit 12:
Bit 28: (sfEES) Front EE Test failed fault
Bit 13: (sfRSR) Reset run fault
Bit 29: (sfERS) Rear EE Test failed fault
Bit 14:
Bit 30:
Bit 15: (sfCOP) COP can comm error
Bit 31:
