GALaxy eHydro Elevator Controller Section 5 – LCD Interface
5-8
Table 5-7: CkStS: Check Start Status State
0 = No Start Op
20 = SUF Fail Off
1 = CCF Off Up
21 = SUF On w/SU
2 = CPU UN Off
22 = Run Up
3 = FSTU Fail On
23 = CPU DN Off
4 = SPD Failed On
24 = FSTD Fail On
5 = MC Failed On
25 = RUND Fail On
6 = MC Failed Off
26 = RUND Fail Off
7 = SPD Fail Off
27 = CPU Out On Dn
8 = RUNU Fail On
28 = CCF On w/RunD
9 = RUNU Fail Off
29 = NTS Out On Dn
10 = CPU Out On Up
30 = NTS DN Off
11 = CCF On w/RunU
31 = SD Failed On
12 = NTS Out On Up
32 = CPU DT Off
12 = NTS UN Off
33 = NTS DT Off
14 = SU Failed On
34 = SDF Failed On
15 = CPU UT Off
35 = SD Failed Off
16 = NTS UT Off
36 = CCF On w/SD
17 = SUF Failed On
37 = SDF Fail Off
18 = SU Failed Off
38 = SDF On/W SD
19 = CCF On w/SU
39 = RUN Down
Table 5-8: CkLevS: Check Level Start Status State
0 = No Level Op
10 = Level Up
1 = CPU UN Off
11 = CPU DN Off
2 = MC Failed Off
12 = RUND Fail On
3 = SPD Fail Off
13 = RUND Fail Off
4 = RUNU Fail On
14 = CPU Out On Dn
5 = RUNU Fail Off
15 = NTS DN Off
6 = CPU Out On Up
16 = SD Failed Off
7 = NTS UN Off
17 = SDF Failed On
8 = SU Failed Off
18 = Level Down
9 = SUF Failed On
