Using the Pre-defined Flushing Programs
The following table displays the default flushing programs that the controller can operate; review the
table that resembles your filtration system.
Parameter
Time between
Flush Cycles
Flushing Time Delay between Filters PDDelay Time
Description
Set the time
between
scheduled
flushing
cycles.
The duration
of the back-
flushing pro-
cess per single
filter in the sys-
tem.
The delay between the
flushing end of a filter
and the flushing start
of the consecutive filter
in the battery.
The time required for
the DP signal to remain
ON until the controller
responds by activating
the flushing cycle.
Program I
Set point 8 hours 25 seconds 10 seconds 30 seconds
Program II
Set point 8 hours 15 seconds 10 seconds 3 seconds
Program III
Set point 8 hours 16 seconds 10 seconds 3 seconds
Program IV
Set point 8 hours 180 seconds 10 seconds 40 seconds
Program V
Set point 8 hours 30 seconds 10 seconds 3 seconds
Program VI
Set point 8 hours 180 seconds 10 seconds 40 seconds
The following table displays the settings resolution and the range of the flushing program parameters:
Parameter Minimum Value Maximum Value Resolution
Time between flush cycles 1 min 99 days 1 min
Flushing time 5 sec 999 sec 1 sec
Main/Downstream valve delay 1 sec 99 sec 1 sec
PDdelay time 1 sec 99 sec 1 sec
Delay valve delay 1 sec 9 sec 1 sec
