MorphoAccess Installation Guide | Edition 11 | April 2019
Copyright © Gallagher Group Limited Page 18
6.4 Physically installing MorphoAccess Readers
Install the reader as per the Morpho installation document supplied with the reader.
6.5 MA Sigma, MA VP and MorphoWave Wiring
Ethernet (T568A standard)
These readers have an internal RJ45 connector which accepts a standard twisted pair cable.
Alternatively, the terminal block can be used:
Reader Cable Colour (T568A standard) PIN # 10BaseT Signal / 100BaseT Signal
RX+
White/Green
1
Transmit +
RX-
Green
2
Transmit -
TX+
White/Orange
3
Receive +
TX-
Orange
4
Receive -
HBUS Wiegand Door Module
MA Sigma / MorphoWave Reader 1
HBUS Wiegand Door Module - Reader 1
Wiegand OUT 0 - Green
R1 DATA 0
Wiegand OUT 1 - White
R1 DATA 1
Wiegand LED 1 - Blue
R1 OUT 1
Wiegand LED 2 - Blue/Red
R1 OUT 2
Wiegand Ground - Red/Black
GND -
MA Sigma / MorphoWave Reader 2
HBUS Wiegand Door Module - Reader 2
Wiegand OUT 0 - Green
R2 DATA 0
Wiegand OUT 1 - White
R2 DATA 1
Wiegand LED 1 - Blue
R2 OUT 1
Wiegand LED 2 - Blue/Red
R2 OUT 2
Wiegand Ground - Red/Black
GND -
MA Sigma / MorphoWave Reader
Power Supply *
12V + (Red)
12V +
GND - (Black)
GND -
* See Power Supply Requirements (on page 20) for further detail.
GBUS Wiegand URI
MA Sigma / MorphoWave Reader 1
GBUS Wiegand URI - Reader 1
Wiegand OUT 0 - Green
R1 DATA 0
Wiegand OUT 1 - White
R1 DATA 1
Wiegand LED 1 - Blue
R1 OUT 1
Wiegand LED 2 - Blue/Red
R1 OUT 2
Wiegand Ground - Red/Black
GND -
MA Sigma / MorphoWave Reader 2
GBUS Wiegand URI - Reader 2
Wiegand OUT 0 - Green
R2 DATA 0
Wiegand OUT 1 - White
R2 DATA 1
Wiegand LED 1 - Blue
R2 OUT 1
Wiegand LED 2 - Blue/Red
R2 OUT 2
Wiegand Ground - Red/Black
GND -
MA Sigma / MorphoWave Reader
Power Supply *
12V + (Red)
12V +
GND - (Black)
GND -
* See Power Supply Requirements (on page 20) for further detail.
