Stability in Potentiostat Mode – Improving Potentiostat Stability
57
This resistor has no effect on the DC accuracy of the potentiostat. It can create problems in high-speed
experiments such as fast CV scans or EIS, which need high bandwidth.
Figure 8-3
Resistor Added for Stability
Red
White
Green
Counter
Reference
Working
Resistor
