G&D DP-HR-CPU Installation And Operation Manual

Console module »DP-HR-CON-MC2«
99 · Computer and console modules (DP-HR)
Technical data
DP-HR-CON-MC2
Interfaces to console Video: 2 × DisplayPort
Keyboard and mouse signals 2 × PS/2 socket
3 × USB-A
Audio: 2 × 3.5 mm jack plug
Tradeswitch-LED: 1 × D-SUB 9 socket
Data transmission to
counterpart
Interfaces: 2 × RJ45 socket
Transmission distance: Max. 140 metres
Video Format: DisplayPort (DP 1.1a)
Colour depth: 24 bit
Video bandwidth: 25 to 300 MP / s, DisplayPort 4 Lanes,
HBR 2.7 Gbps
Max. resolution:  2560 × 1600 (60 Hz)
 4096 × 2160 (30 Hz)
Examplary resolutions:  4096 × 2160 (24 , 25 or 30 Hz)
 3840 × 2160 (24, 25 or 30 Hz)
 2048 × 2160 (60 Hz)
 2048 × 2048 (60 Hz)
 1920 × 1080 (50 or 60 Hz)
 1440 × 576i (50 Hz)
 1440 × 480i (60 Hz)
 Further standardised resolutions
within the video bandwith possible.
Vertical frequency: 24 Hz to 120 Hz
Horizontal frequency: 25 kHz to 135 kHz
DDC/CI: The device supports monitors with a
DDC/CI function. The DDC information
are transparently forwarded to the
monitor to support a maximum number
of monitors. However, the support
cannot be guaranteed for all monitor
models.
Audio
 DisplayPort Digital
Transmission type: 2 channel LPCM, stereo
Resolutions: 16/20/24 bit
Sampling rates: up to 48 kHz
Audio Transmission type: transparent, bidirectional
Resolution: 24 bits
Refresh rate: 96 kHz
Bandwidth: 22 kHz
