Console module »DP-HR-CON-Fiber-MC4«

133 · Computer and console modules (DP-HR)

Console module

»DP-HR-CON-Fiber-MC4«

With DP-HR-CON-Fiber-MC4 console modules, you can connect a dual-monitor console

(four

DisplayPort monitors, keyboard, mouse and audio devices) to a digital matrix

switch of the ControlCenter-Compact or ControlCenter-Digital series.

At the installed console, matrix switch users can access a computer module to operate

the connected computer.

When using the console to access a multi-monitor computer with four graphics out-

puts, the separate images of the graphics outputs are displayed on the console moni-

tors.

When accessing the system with a computer module with only one graphics input,

only the first monitor shows an image.

Package contents

 1 × Console module DP-HR-CON-Fiber-MC4

 1 × Power cable

 1 × »Manual information« flyer

 1 × »Safety instructions« flyer

NOTE:

This console module can be connected to a compatible fiber port of

ControlCenter-Compact matrix switches or ControlCenter-Digital matrix switches

(requires CCD-I/O 16-Card-Fiber).

IMPORTANT:

Both, the console module and the fiber ports are available as single-

mode variants or as multimode variants. Make sure that the port at the console module,

the fiber port and the optical fibers are compatible with each other.

NOTE:

Connecting a multi-monitor computer with four video outputs requires four

computer modules of the

DP-HR-CPU series or two computer modules of the DP-HR-

CPU-MC2

series.

In the web application, you can add the computer modules of the multi-monitor

computers to a channel groups More information about this topic is given in the

chapter Expanding the system through port grouping of the web application manual.
