Computer module »DP-HR-CPU-Fiber-MC2«
Computer and console modules (DP-HR) · 40
Computer module
»DP-HR-CPU-Fiber-MC2«
With DP-HR-CPU-Fiber-MC2 computer modules, you can connect a computer with Dis-
playPort graphics outputs (dual-head) to a digital matrix switch of the ControlCenter-
Compact or ControlCenter-Digital series.
Users at the consoles of the matrix switch can access the computer module and operate
the connected computer.
Package contents
 1 × Computer module DP-HR-CPU-Fiber-MC2
 2 × DisplayPort video cable (DP-Cable-M/M-2)
 1 × USB device cable
 2 × Audio cable
 1 × Power pack (12V/2A, only with variants incl. PowerPack)
 1 × Power cable (only with variants incl. PowerPack)
 1 × »Manual information« flyer
 1 × »Safety instructions« flyer
NOTE: This computer module can be connected to a compatible fiber port of
ControlCenter-Compact matrix switches or ControlCenter-Digital matrix switches
(requires
CCD-I/O 16-Card-Fiber).
IMPORTANT: Both, the computer module and the fiber ports are available as single-
mode variants or as multimode variants. Make sure that the port at the computer
module, the fiber port and the optical fibers are compatible with each other.
