Computer module »DP-HR-CPU-Fiber-MC2-UC«
47 · Computer and console modules (DP-HR)
Computer module
»DP
-HR-CPU-Fiber-MC2-UC«
With DP-HR-CPU-Fiber-MC2-UC computer modules, you can connect a computer with
two
DisplayPort graphics outputs (dual-head) to two different digital matrix switches of
the ControlCenter-Compact or ControlCenter-Digital series.
At the consoles of both matrix switches, users can access a computer module to
operate the connected computer.
Package contents
 1 × Computer module DP-HR-CPU-Fiber-MC2-UC
 2 × DisplayPort video cable (DP-Cable-M/M-2)
 1 × USB device cable
 2 × Audio cable
 1 × Power pack (12V/2A, only with variants incl. PowerPack)
 1 × Power cable (only with variants incl. PowerPack)
 1 × »Manual information« flyer
 1 × »Safety instructions« flyer
Required accessories
 4 × Compatible optical fibre cable to connect the computer module to
the matrix switch
NOTE: This computer module can be connected to a compatible fiber port of
ControlCenter-Compact matrix switches or ControlCenter-Digital matrix switches
(requires CCD-I/O 16-Card-Fiber).
IMPORTANT: Both, the computer module and the fiber ports are available as single-
mode variants or as multimode variants. Make sure that the port at the computer
module, the fiber port and the optical fibers are compatible with each other.
IMPORTANT: Only consoles configured for multi-monitor operation via channel
grouping can show the images of both of the computer’s video outputs on separate
monitors.
At consoles with one monitor only, the image of the computer’s second video out-
put is not displayed.
