Console module »DP-HR-CON-2-Fiber«
117 · Computer and console modules (DP-HR)
Console module »DP-HR-CON-2-Fiber«
With DP-HR-CON-2-Fiber console modules, you can connect a console (DisplayPort
monitor, keyboard, mouse and audio devices) to two digital matrix switches of the
ControlCenter-Compact or ControlCenter-Digital series.
At the installed console, matrix switch users can access a computer module to operate
the connected computer.
The buttons on the front panel of the console module or configured key combina-
tions (select keys) let users switch between the connected matrix switches.
Package contents
 1 × DP-HR-CON-2-Fiber console module
 1 × Power cable
 1 × »Manual information« flyer
 1 × »Safety instructions« flyer
NOTE: This console module can be connected to a compatible fiber port of
ControlCenter-Compact matrix switches or ControlCenter-Digital matrix switches
(requires CCD-I/O 16-Card-Fiber).
IMPORTANT: Both, the console module and the fiber ports are available as single-
mode variants or as multimode variants. Make sure that the port at the console module,
the fiber port and the optical fibers are compatible with each other.
ADVICE: Instead of a matrix switch, you can also connect a compatible computer
module to each of the two channels.
