Console module »DP-HR-CON-DH«
Computer and console modules (DP-HR) · 148
Technical data
DP-HR-CON-DH
Interfaces to console Video: 2 × DisplayPort
Keyboard and mouse signals 2 × PS/2 socket
3 × USB-A
Audio: 2 × 3.5 mm jack plug
Tradeswitch-LED: 1 × D-SUB 9 socket
Data transmission to
counterpart
Interfaces: 1 × RJ45 socket
Transmission distance: Max. 140 metres
Video Format: DisplayPort (DP 1.1a)
Colour depth: 24 Bit
Video bandwidth: 25 to 300 MP/s (Channel 1)
25 to 165 MP/s (Channel 2)
Max. 330 MP/s (total)
Examplary resolutions: Channel 1:
 2048 × 2048 @ 60 Hz (2K×2K)
 2048 × 2160 @ 60 Hz
 2560 × 1600 @ 60 Hz
 3840 × 2160 @ 30 Hz (Ultra HD)
 4096 × 2160 @ 30 Hz (4K)
 1920 × 1080 (50 or 60 Hz)
 1440 × 576i (50 Hz)
 1440 × 480i (60 Hz)
Channel 2:
 1920 × 1200 @ 60 Hz
 1280 × 1024 @ 85 Hz
 1080p60 (Full HD)
 640 × 480 @ 60 Hz
 Further VESA and CTA standardised
resolutions possible within video
bandwidth/pixel rate and
horizontal/vertical frequency.
Vertical frequency: 24 Hz to 120 Hz
Horizontal frequency: 25 kHz to 135 kHz
DDC/CI: The device supports monitors with a
DDC/CI function. The DDC information
are transparently forwarded to the
monitor to support a maximum number
of monitors. However, the support
cannot be guaranteed for all monitor
models.
Audio
 DisplayPort Digital
Transmission type: 2 channel LPCM, stereo
Resolutions: 16/20/24 bit
Sampling rates: up to 48 kHz
