Console module »DP-HR-CON-2-DH«
Computer and console modules (DP-HR) · 158
Audio Transmission type: transparent, bidirectional
Resolution: 24 Bit
Sampling rate: 96 kHz
Bandwidth: 22 kHz
Main power supply Type: Internal power pack
Connection: 1 × IEC plug (IEC-320 C14)
Power input: 100 - 240 VAC; 0.3 A - 0.2 A
Redundant
power supply
optional
Type: Portable power pack (12 V/2 A)
Connection: 1 × Mini-DIN 4 socket (Power In)
Power input: 1.3A @ 12 VDC
Casing Material: Anodised aluminium
Dimensions (W × H × D): Approx. 210 × 44 × 210 mm
Weight: Approx. 1.3 kg
Operating
environment
Temperature: +5 °C to +45 °C
Air humidity: 20 % to 80 %, non-condensing
Storage
environment
Temperature: -20°C to +55°C
Air humidity: 15 % to 85 %, non-condensing
Conformity CE, UKCA, FCC class B, TAA, EAC, RoHS,
WEEE, REACH
DP-HR-CON-2-DH
