G&D DP-HR-CPU Installation And Operation Manual

Console module »DP-HR-CON-Fiber-DH«
163 · Computer and console modules (DP-HR)
Power supply
Main Power: Connect the supplied power cable. Insert the cable’s Schuko plug in a
power socket.
Red. Power: Connect the connection cable of a compatible power pack to provide the
console module with a second, redundant power supply.
Startup
Turn on the console module after its installation.
Use the Main Power power pack or a redundant power pack to establish the power
supply:
 Turn on the Main Power power pack.
 Use an optional power pack to supply the Red. Power socket with power.
Micro In
Speaker Keyb./Mouse
Generic
LED Out
Mouse
Keyb.
DisplayPort
Out 1 Out 2
Transmission
Main Power
Red. Power
