Console module »DP-HR-CON-2-Fiber-DH«
Computer and console modules (DP-HR) · 176
Video Vertical frequency: 24 Hz to 120 Hz
Horizontal frequency: 25 kHz to 135 kHz
DDC/CI: The device supports monitors with a
DDC/CI function. The DDC information
are transparently forwarded to the moni
-
tor to support a maximum number of
monitors. However, the support cannot
be guaranteed for all monitor models.
Audio
DisplayPort Digital
Transmission type: 2 channel LPCM, stereo
Resolutions: 16/20/24 bit
Sampling rates: up to 48 kHz
Audio Transmission type: transparent, bidirectional
Resolution: 24 bits
Refresh rate: 96 kHz
Bandwidth: 22 kHz
Main power supply Type: Internal power pack
Connector: 1 × IEC plug (IEC-320 C14)
Power input: 100 - 240 VAC; 0.4 A - 0.2 A
Redundant
power supply
Type: External power pack
Connector: 1 × Mini-DIN 4-Buchse
Power input: 1.4A @ 12 VDC
Housing Material: Anodised aluminium
Dimensions (W × H × D): Approx. 210 × 44 × 210 mm
Weight: Approx. 1.3 kg
Operating
environment
Temperature: +5 °C to +45 °C
Air humidity: 20 % to 80 %, non-condensing
Storage
environment
Temperature: -20°C to +55°C
Air humidity: 15 % to 85 %, non-condensing
Conformity CE, UKCA, FCC class B, TAA, EAC, RoHS,
WEEE, REACH
DP-HR-CON-2-FIBER-DH
