G&D DP-HR-CPU Installation And Operation Manual

Computer module »DP-HR-CPU-Fiber-DH-UC«
Computer and console modules (DP-HR) · 78
DP-HR-CPU-FIBER-DH-UC
Video Examplary resolutions: Channel 1:
 2048 × 2048 @ 60 Hz (2K×2K)
 2048 × 2160 @ 60 Hz
 2560 × 1600 @ 60 Hz
 3840 × 2160 @ 30 Hz (Ultra HD)
 4096 × 2160 @ 30 Hz (4K)
 1920 × 1080 (50 or 60 Hz)
 1440 × 576i (50 Hz)
 1440 × 480i (60 Hz)
Channel 2:
 1920 × 1200 @ 60 Hz
 1280 × 1024 @ 85 Hz
 1080p60 (Full HD)
 640 × 480 @ 60 Hz
 Further VESA and CTA standardised
resolutions possible within video
bandwidth/pixel rate and
horizontal/vertical frequency.
DDC/CI: The device supports monitors with a
DDC/CI function. The DDC information
are transparently forwarded to the moni
-
tor to support a maximum number of
monitors. However, the support cannot
be guaranteed for all monitor models.
Audio
 DisplayPort Digital
Transmission type: 2 channel LPCM, stereo
Resolutions: 16/20/24 bit
Sampling rates: up to 48 kHz
Audio Transmission type: transparent, bidirectional
Resolution: 24 Bit
Refresh rate: 96 kHz
Bandwidth: 22 kHz
Power supply Type: Portable power pack (12 V/2 A)
Connector: 1 × Mini-DIN 4 socket
Power input: 0.8A @ 12 VDC
Housing Material: Anodised aluminium
Dimensions (W × H × D): Approx. 105 × 26 × 164 mm
Weight: Approx. 0.43 kg
Operating
environment
Temperature: +5 °C to +45 °C
Air humidity: 20 % to 80 %, non-condensing
Storage
environment
Temperature: -20°C to +55°C
Air humidity: 15 % to 85 %, non-condensing
Conformity CE, UKCA, FCC class B, TAA, EAC, RoHS,
WEEE, REACH
