Console module »DP-HR-CON«
81 · Computer and console modules (DP-HR)
Connection to the matrix switch
Transmission: Use a category 5e (or better) twisted pair cable to connect the Transmis-
sion interface to a Dynamic Port (RJ45) of the matrix switch.
Power supply
Main Power: Connect the power cable to the power pack and a power outlet.
Red. Power: If required, connect the power cable of the optional power pack to this
interface. This provides a redundant power supply. Connect the power cable with
the power pack and a power outlet of a different power circuit.
Start-up
Start the console module by pressing the Main Power button of the power pack.
NOTE:
You can also connect the console module directly to a compatible computer
module.
ADVICE:
The active hotkey configuration is displayed during the System Startup of
the matrix switch.
