Console module »DP-HR-CON«
85 · Computer and console modules (DP-HR)
DP-HR-CON
Main power supply Type: Internal power pack
Connection: 1 × IEC plug(IEC-320 C14)
Current consumption: 100 - 240 VAC; 0.3 A - 0.2 A
Redundant
power supply
Type: External power pack (12 V/2 A)
Connection: 1 × Mini-DIN 4 socket (Power In)
Current consumption: 1.1A @ 12 VDC
Casing Material: Anodised aluminium
Dimensions (W × H × D): Approx. 210 × 44 × 210 mm
Weight: Approx. 1.22 kg
Operating
environment
Temperature: +5 °C to +45 °C
Air humidity: 20 % to 80 %, non-condensing
Storage
environment
Temperature: -20°C to +55°C
Air humidity: 15 % to 85 %, non-condensing
Conformity CE, UKCA, FCC class B, TAA, EAC, RoHS,
WEEE, REACH
