Console module »DP-HR-CON-2«
Computer and console modules (DP-HR) · 88
Connection to the matrix switch
Transmission 1: Connect this interface to a Dynamic Port (RJ45) of the matrix switch.
Transmission 2: Connect this interface to another Dynamic Port (RJ45) of the matrix
switch.
Power supply
Main Power: Connect the power cable to the power pack and a power outlet.
Red. Power: If required, connect the power cable of the optional power pack to this
interface. This provides a redundant power supply. Connect the power cable with
the power pack and a power outlet of a different power circuit.
Start-up
Start the console module by pressing the Main Power button of the power pack.
Switching
The buttons on the front panel of the console module or configured key combina-
tions (select keys) let users switch between the connected matrix switches.
How to switch channels via buttons:
Press the button of the desired channel to activate it.
How to switch channels via key combinations:
On the console keyboard, press local hotkey+Select key.
In the default settings, the select keys are Alt+1 (channel 1) and Alt+2 (channel 2).
NOTE:
Use category 5e (or better) twisted pair cables to connect the devices.
ADVICE:
You can also connect the Transmission interface directly to a compatible
computer
module.
ADVICE:
The active hotkey configuration is displayed during the System Startup of
the matrix switch and the console module.
