GAT NET.Lock 7020 System
Technical Data
www.gantner.com HB_GAT-NETLOCK7020--EN_12 61
7.3 GAT NET.Controller M 7020 (Light)
Nominal voltage: DC 24 V
Power supply unit: External power supply (GAT NET.Power Supply 100-240V / VI)
Power consumption: Approx. 3 W
Memory: Internal memory for 10,000 bookings. SD card slot for memory
expansion, log files, firmware update, or user lists.
Interface to server: Ethernet
GAT Lock Network
- GAT NET.Controller M 7020: Max. 8 GAT NET.Controller S 7020 sub controllers
- GAT NET.Controller M 7020 Light: Max. 3 GAT NET.Controller S 7020 sub controllers
Connectors
- Master to server (Ethernet): RJ45
- Sub to master (RS-485): RJ45
- Power: 6-pin MOLEX
Digital inputs
- GAT NET.Controller M 7020: - 4 x optocouplers (function configurable)
- Input voltage: DC 6 to 30 V
- Input current: 4.5 mA
- GAT NET.Controller M 7020 Light: No inputs
Digital outputs
- GAT NET.Controller M 7020: - 4 x relays (NO/NC, function configurable)
- Switching voltage: max. 30 VAC/DC
- Limiting continuous current: max. 2 A
- Switching power: max. 60 VA
- GAT NET.Controller M 7020 Light: No outputs
Housing material: Plastic (ABS - VO)
Dimensions: 310 x 133 x 42 mm (12.2 x 5.24 x 1.65 in)
Weight: Approx. 600 g (21.2 oz)
Permitted ambient temperature: 0 °C to +60 °C (32 °F to 140 °F)
Protection type: IP 40
Protection class: I
Environment class based on VdS 2110: II (conditions in indoor areas)
Compliance: CE, FCC, IC, ETL
