GarageSmart
TM
User’s Manual
23
4. Rotate the bottom PCB as shown below, then re-install the (4) PCB screws and
connect the buzzer connector to the J3 terminal on the PCB.
5. Continue with the installation and wiring per the section above.
Bottom PCB
J3
