Technical Specifications
GarageSmart™ GS100-CR
Input Voltage: 24VDC or 24VAC
Input Current: 25mA (Normal Operation), 250mA (Lights/Buzzer Indication)
AUX Outputs: 60V / 1-Amp (each relay)
Temperature Range: -20 degrees C to +55 degrees C
Relative Humidity Range: 0 - 95% Non-Condensing
Wi-Fi Radio 802.11 b/g/n/ac (2.4 GHz)
TX Power 802.11b +20 dBm
802.11g +17 dBm
802.11n +14 dBm
Operation Wi-Fi Range Typical Ranges*
802.11b 115 feet indoors
802.11g 115 feet indoors
802.11n 230 feet indoors
* Typical ranges are dependent on the user’s router transmission
power, antenna type, the location, and the environment. Ranges
have been reported to be longer than the Typical Ranges shown
above.
Radio Certification FCC, CE, TELEC, SRRC
Ingress Protection IP66**
NEMA Enclosure 4X**
** The top opening of enclosure (where wires enter the
GarageSmart™ device) must be sealed by the user, by use of ¾
conduit or equivalent and gaskets.
