Do not use any tools to do so.
7. IDLE SPEED ADJUSTMENT
If the cutting attachment still rotates in idle speed, contact Authorized Service Centers
for correct idle speed adjustment.
Note: When the engine is idling the cutting attachment must rotate under no cir-
cumstances!
VII. OPERATION
Please note that the statutory regulations governing noise abatement may differ
from one location to another.
Each time before use, check the following:
- That there are no leaks in the fuel system.
- That the equipment is in perfect condition and that the safety devices and
cutting devices are complete.
- That all screws are securely fastened.
- That all moving parts move smoothly.
Starting the engine when cold (See Fig. 21 & Fig. 27)
Fill up the fuel tank with the relevant mixture of petrol and oil (Fig. 21), and also
top up the chain oil (Fig. 21). See the section 'Fuel and oil'.
Disengage the chain brake
1. Switch the stop switch to '0' (OFF) (Fig. 19).
2. Pull the choke (17) fully out until it locks (Fig. 18/arrow direction 1).
3. Push the primer bubble (23) 10 times (Fig. 1).
4. Place the saw on a rm, at surface. Hold the saw rmly as shown. Pull the
starter cord (7) rapidly 2 times. (Fig. 22 & Fig. 27) Beware of moving chain!
5. Push in the choke lever as far as it will go (Fig. 18/arrow direction 2).
6. Switch the stop switch to 'I' (ON) to start the machine (Fig. 19/right).
7. Hold the saw rmly and pull the starter rapidly 4 times. Engine should start
(Fig. 22 & Fig. 27).
m CAUTION
Never allow the starter line to snap back when it has been pulled out.
This may result in damage.
38
AFTER SALES SUPPORT
aldi.service.uk@scheppach.com
00800 4003 4003
MODEL: CSP41 PRODUCT CODE: 64055 04/2017
Set up/Operation Petrol chainsaw 41cc
