Part #: GAR_IOM_ 4532522 Rev 08—6/17 19
Section 1 General Information
Model #
220V, 3L (DELTA), 50/60Hz 230V,3L (DELTA), 50/60Hz 240V, 3L (DELTA), 50/60Hz
Current (A) Power Current (A) Power Current (A) Power
L1 L2 L3 (kW) L1 L2 L3 (kW) L1 L2 L3 (kW)
XPE 12 22.0 23.7 22.9 7.9 21.2 23.0 22.0 8.0 20.7 22.6 21.6 8.0
XPE 12 0L/R 13.8 15.6 22.9 5.3 13.8 15.4 22.0 5.3 13.8 15.1 21.6 5.3
XPE-24 1 INPUT 42.7 43.0 43.0 15.8 40.1 40.6 40.6 16.0 39.1 39.5 39.5 16.0
XPE-24 2 INPUT CORD 1 22.8 23.6 22.0 7.9 21.9 22.9 21.2 7.9 21.5 22.5 20.7 7.9
XPE-24 2 INPUT CORD 2 22.8 22.2 23.8 7.9 21.9 21.4 23.1 8.0 21.5 20.9 22.7 8.0
XPE-24 0L/R 1 INPUT 42.7 24.9 24.9 10.5 40.1 23.3 23.3 10.6 39.1 22.8 22.8 10.6
XPE-24 0L/R 2 INPUT CORD 1 22.8 15.5 13.8 5.2 21.9 15.3 13.8 5.3 21.5 15.0 13.8 5.3
XPE-24 0L/R 2 INPUT CORD 2 22.8 14.0 15.7 5.2 21.9 14.0 15.5 5.4 21.5 14.0 15.2 5.3
XPE-24 1L 1 INPUT 42.7 32.8 32.8 13.1 40.1 30.9 30.9 13.3 39.1 30.0 30.0 13.3
XPE-24 1L 2 INPUT CORD 1 22.8 23.6 22.0 7.9 21.9 22.9 21.2 7.9 21.5 22.5 20.7 7.9
XPE-24 1L 2 INPUT CORD 2 22.8 14.0 15.7 5.2 21.9 14.0 15.5 5.4 21.5 14.0 15.2 5.3
XPE-24 1R 1 INPUT 42.7 32.8 32.8 13.1 40.1 30.9 30.9 13.3 39.1 30.0 30.0 13.3
XPE-24 1R 2 INPUT CORD 1 22.8 15.5 13.8 5.2 21.9 15.3 13.8 5.3 21.5 15.0 13.8 5.3
XPE-24 1R 2 INPUT CORD 2 22.8 22.2 23.8 7.9 21.9 21.4 23.1 8.0 21.5 20.9 22.7 8.0
XPE-36 2 INPUT CORD 1 23.6 22.8 22.0 7.9 22.9 21.9 21.2 8.0 22.5 21.5 20.7 7.9
XPE-36 2 INPUT CORD 2 42.7 43.0 43.0 15.8 40.1 40.6 40.6 16.0 39.1 39.5 39.5 16.0
XPE-36 0L/R 2 INPUT CORD 1 15.5 13.8 22.8 5.2 15.3 13.8 21.9 5.3 15.0 13.8 21.5 5.3
XPE-36 0L/R 2 INPUT CORD 2 42.7 24.9 24.9 10.5 40.1 23.3 23.3 10.6 39.1 22.8 22.8 10.6
XPE-36 1L 2 INPUT CORD 1 23.6 22.8 22.0 7.9 22.9 21.9 21.2 8.0 22.5 21.5 20.7 7.9
XPE-36 1L 2 INPUT CORD 2 42.7 24.9 24.9 10.4 40.1 23.3 23.3 10.5 39.1 22.8 22.8 10.5
XPE-36 1R 2 INPUT CORD 1 22.8 15.5 13.8 5.2 21.9 15.3 13.8 5.3 21.5 15.0 13.8 5.3
XPE-36 1R 2 INPUT CORD 2 42.7 32.8 32.8 13.1 40.1 30.9 30.9 13.2 39.1 30.0 30.0 13.2
XPE-36 2L 2 INPUT CORD 1 23.6 22.8 22.0 7.9 22.9 21.9 21.2 8.0 22.5 21.5 20.7 7.9
XPE-36 2L 2 INPUT CORD 2 42.7 32.8 32.8 13.1 40.1 30.9 30.9 13.2 39.1 30.0 30.0 13.2
XPE-36 2R 2 INPUT CORD 1 22.8 15.5 13.8 5.2 21.9 15.3 13.8 5.3 21.5 15.0 13.8 5.3
XPE-36 2R 2 INPUTCORD 2 42.7 43.0 43.0 15.8 40.1 40.6 40.6 16.0 39.1 39.5 39.5 16.0
Electrical Input Specification - DELTA (Electric models), continuation
