Section 1 General Information
Gas Elevations Settings
Determining Unit Configuration for Gas Grills continuation:
b. If the grill has been supplied with the following label, it has been configured for high elevation. The elevation and gas
type for the unit is indicated by the punched hole in the “Appliance Set For” section. For example, on the label shown
below, the unit is configured for Natural gas between 7001 and 9500 feet (2135 and 2896 meters).
HIGH ELEVATION GAS SETTINGS/SPECIFICATIONS FOR CSA APPROVED MODELS
GAS TYPE
ELEVATION
RANGE
FAN
SPEED
PRESSURE
SWITCH SETTING
¹INPUT/
BURNER
²TOTAL INPUT/UNIT
BTU
SUPPLY
PRESSURE
MANIFOLD
PRESSURE
INJECTOR
SIZE
FEET RPM
" W.C.
CLOSE /
OPEN
Colour
Code
BTU
12in
GRILL
24in
GRILL
36in
GRILL
" W.C. " W.C. mm
Natural Gas
CSA
4501 - 7000 11,000
0.15 /
0.07
Grey
8,900 17,800 35,600 53,400
7.0 4.0 1.57001 - 9500 11,750 8,500 17,000 34,000 51,000
9501 - 12000 12,250 8,100 16,200 32,400 48,600
Propane Gas
CSA
4501 - 7000 11,000
0.15 /
0.07
Grey
8,900 17,800 35,600 53,400
11.0 4.0 1.27001 - 9500 11,100 8,700 17,400 34,800 52,200
9501 - 12000 11,200 8,500 17,000 34,000 51,000
¹Input per burner based on the middle of the elevation range, ²Calculated based on Input/Burner
Figure label #2
