Garland XPG24 User Manual

Part #: GAR_IOM_ 4532522 Rev 08—6/17 21
Section 1 General Information
XPG-24 CE Models (gas models)
Model
Volts
3NɎ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
220V/380V 4.7 12.6 16.7 6.8
230V/400V 4.7 11.8 15.5 6.9
240V/415V 4.7 11.8 15.6 6.9
XPG-24 Models (gas models)
Model
Volts
3Ɏ50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
200V 22.9 16.8 28.3 7.0
208V 20.5 16.5 27.6 7.0
220V 18.8 15.0 25.1 6.8
230V 18.0 14.2 23.7 6.9
240V 17.8 14.1 23.5 6.9
XPG-24 1L Models (gas models)
Model
Volts
3Ɏ50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
200V 20.9 4.7 18.4 4.2
208V 20.5 4.8 18.0 4.3
220V 18.8 4.7 16.4 4.2
230V 18.0 4.7 15.6 4.2
240V 17.8 4.7 15.4 4.2
XPG-24 1L CE Models (gas models)
Model
Volts
3NɎ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
220V/380V 4.7 0.0 16.7 4.2
230V/400V 4.7 0.0 15.5 4.2
240V/415V 4.7 0.0 15.6 4.2
XPG-24 (0L,0R) CE Models (gas models)
Model
Volts
3NɎ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
220V/380V 4.7 0.0 4.7 1.5
230V/400V 4.7 0.0 4.7 1.5
240V/415V 4.7 0.0 4.7 1.5
XPG-24 (0L,0R) Models (gas models)
Model
Volts
3Ɏ50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
200V 7.9 4.7 4.7 1.5
208V 8.0 4.8 4.8 1.6
220V 7.7 4.7 4.7 1.5
230V 7.7 4.7 4.7 1.5
240V 7.6 4.7 4.7 1.5
XPG-24 1R Models (gas models)
Model
Volts
3Ɏ50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
200V 7.9 16.8 16.8 4.2
208V 8.0 16.5 16.5 4.3
220V 7.7 15.0 15.0 4.2
230V 7.7 14.2 14.2 4.2
240V 7.6 14.1 14.1 4.2
XPG-24 1R CE Models (gas models)
Model
Volts
3NɎ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
220V/380V 4.7 12.6 4.7 4.2
230V/400V 4.7 11.8 4.7 4.2
240V/415V 4.7 11.8 4.7 4.2
Electrical Input Specification - WYE (gas XPG-24 CE models)
Electrical Input Specification - DELTA (gas XPG-24 models)
