Garland XPG24 User Manual

22 Part #: GAR_IOM_ 4532522 Rev 08—6/17
General Information Section 1
XPG-36 CE Models (gas models)
Model
Volts
3NɎ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
3
Platen
220V/380V 16.7 16.7 16.7 10.2
230V/400V 15.5 15.5 15.5 10.3
240V/415V 15.6 15.6 15.6 10.3
XPG-36 Models (gas models)
Model
Volts
3Ɏ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
3
Platen
200V 31.7 31.7 31.7 10.4
208V 30.9 30.9 30.9 10.6
220V 28.3 28.3 28.3 10.2
230V 27.3 27.3 27.3 10.3
240V 26.1 26.1 26.1 10.3
XPG-36 1L CE Models (gas models)
Model
Volts
3NɎ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
3
Platen
220V/380V 4.7 4.7 16.7 4.9
230V/400V 4.7 4.7 15.5 5.0
240V/415V 4.7 4.7 15.6 5.0
XPG-36 2L CE Models (gas models)
Model
Volts
3NɎ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
3
Platen
220V/380V 16.7 4.7 16.7 7.6
230V/400V 15.5 4.7 15.5 7.7
240V/415V 15.6 4.7 15.6 7.6
XPG-36 (0L/R) CE Models (gas models)
Model
Volts
3NɎ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
3
Platen
220V/380V 4.7 4.7 4.7 2.3
230V/400V 4.7 4.7 4.7 2.3
240V/415V 4.7 4.7 4.7 2.3
XPG-36 (0L/R) Models (gas models)
Model
Volts
3Ɏ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
3
Platen
200V 7.0 7.0 7.0 2.3
208V 6.9 6.9 6.9 2.3
220V 6.3 6.3 6.3 2.3
230V 6.1 6.1 6.1 2.3
240V 5.8 5.8 5.8 2.3
XPG-36 1R CE Models (gas models)
Model
Volts
3NɎ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
3
Platen
220V/380V 4.7 16.7 4.7 4.9
230V/400V 4.7 15.5 4.7 5.0
240V/415V 4.7 15.6 4.7 5.0
XPG-36 2R CE Models (gas models)
Model
Volts
3NɎ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
3
Platen
220V/380V 16.7 16.7 4.7 7.6
230V/400V 15.5 15.5 4.7 7.7
240V/415V 15.6 15.6 4.7 7.6
Electrical Input Specification - WYE (gas XPG-36 CE models)
Electrical Input Specification - DELTA (gas XPG-36 models)
