General Information Section 1
XPE-24 CE Models (electric models)
Model
Volts
3NɎ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
220V/380V 27.3 24.9 27.1 15.8
230V/400V 26.4 23.9 25.8 15.9
240V/415V 26.4 23.7 25.8 15.9
XPE-24 Models (electric models)
Model
Volts
3Ɏ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
200V 51.6 48.7 49.4 16.0
208V 50.8 48.1 48.4 16.2
220V 46.8 45.1 44.6 15.8
230V 44.9 43.9 42.8 15.9
240V 44.5 43.0 42.3 15.9
XPE-24 1L Models (electric models)
Model
Volts
3Ɏ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
200V 51.6 37.8 38.8 13.3
208V 50.8 37.5 38.1 13.5
220V 46.8 35.5 35.1 13.1
230V 44.9 35.1 33.7 13.2
240V 44.5 34.8 33.5 13.2
XPE-24 1L CE Models (electric models)
Model
Volts
3NɎ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
220V/380V 27.3 13.8 2701 13.1
230V/400V 26.4 13.8 25.8 13.2
240V/415V 26.4 13.8 25.8 13.2
XPE-24 (0L,0R) CE Models (electric models)
Model
Volts
3NɎ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
220V/380V 27.3 13.8 15.2 10.4
230V/400V 26.4 13.8 14.6 10.5
240V/415V 26.4 13.8 14.6 10.5
XPE-24 (0L,0R) Models (electric models)
Model
Volts
3Ɏ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
200V 40.0 37.8 25.8 10.6
208V 39.6 37.5 25.6 10.8
220V 36.8 35.5 24.1 10.4
230V 35.7 35.1 23.5 10.5
240V 35.4 34.8 23.4 10.5
XPE-24 1R Models (electric models)
Model
Volts
3Ɏ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
200V 40.0 48.7 37.9 13.3
208V 39.6 48.1 37.1 13.5
220V 36.8 45.1 34.5 13.1
230V 35.7 43.9 33.3 13.2
240V 35.4 43.0 33.0 13.2
XPE-24 1R CE Models (electric models)
Model
Volts
3NɎ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
2
Platen
220V/380V 27.3 24.9 15.2 13.1
230V/400V 26.4 23.9 14.6 13.2
240V/415V 26.4 23.7 14.6 13.2
Electrical Input Specification - WYE (electric XPE-24 CE models)
Electrical Input Specification - DELTA (electric XPE-24 models)
