24 Document: GAR_SM_4601777 (4/16)
General Information Section 1
Gas Input Specification
Gas Grills, 1, 2 & 3 Platen North America - all CSA models.
GAS
MAX INPUT
NET PER
BURNER
BTU/H
TOTAL INPUT
RATING
BTU/H
INJECTOR
SIZE
SUPPLY PRESSURE
IN W.C.
BURNER MANIFOLD
PRESSURE
IN W.C.
1
Platen
NATURAL GAS
10,000
20,000 1.5mm 7.0” WC
4.0” WC
PROPANE 20,000 1.2mm 11.0” WC
2
Platen
NATURAL GAS 40,000 1.5mm 7.0” WC
PROPANE 40,000 1.2mm 11.0” WC
3
Platen
NATURAL GAS 60,000 1.5mm 7.0” WC
PROPANE 60,000 1.2mm 11.0” WC
Input Speci cation - All CE Models.
GAS
GROUP
MAX INPUT NET
PER BURNER kW
TOTAL INPUT RATING kW
INJECTOR
SIZE mm
BURNER
PRESSURE mbar
FAN SPEED
SETTING (RPM)
G20 2.93
5.86kW - (For XPE12 series)
11.72kW - (For XPE24 series)
17.58kW - (For XPE36 series)
1.5mm
10mbar
(4.0” WC)
10,000G25 2.93
5.86kW - (For XPE12 series)
11.72kW - (For XPE24 series)
17.58kW - (For XPE36 series)
1.5mm
13.7mbar
(5.5” WC)
G31 2.93
5.86kW - (For XPE12 series)
11.72kW - (For XPE24 series)
17.58kW - (For XPE36 series)
1.2mm
10mbar
(4.0” WC)
For G31 propane gas, the unit has been set at the factory for a 37mbar supply pressure. A factory authorized service
technician must adjust the unit if a 30mbar supply pressure is used.
COUNTRY GAS CATEGORY GAS TYPE SUPPLY PRESSURE (mbar)
AT, CH, CY, CZ, DK, EE, ES, FI, FR, GB, GR, HR, IE, IT, LT, LU,
LV, NL, NO, PT, RO, SE, SI, SK, TR
I2H G20 20
HU I2H G20 25
DE, LU, PL, RO I2E G20 20
BE I2E(R) G20 20
FR I2E(r) G20/G25 20/25
FR, NL I2L G25 25
RO I2L G25 20
FI, HU,NL, RO I3P G31 30
BE, CH, CZ, ES, FR, GB, GR, HU, IE, IT, LT, NL, PL, PT, SI, SK,
HR
I3P G31 37
AT, BE, CH, CZ, DE, ES, FR, GB, GR, HU, NL, SK I3P G31 50
NOTE: For installations up to 2000ft. units being installed at higher elevation must be configured accordingly at the factory
or modified at the installation site by a factory authorized service technician.
