Specifications
Specifications
All Models
Material Polycarbonate plastic
Water rating IEC60529IPX7
3
Temperature range From -15° to 55°C (from 5° to 131°F)
Input voltage From 9 to 18Vdc
Fuse 3A, 125V fast-acting
Memory card 1 microSD card slot; 32GB max. card size
Display resolution WVGA , 800 x 480 pixels
Sonar frequencies
4
Traditional: 50/200, 77/200, 83/200kHz
Single Channel CHIRP: from 40 to 250kHz
Garmin ClearVü CHIRP: 260/455/800kHz
Sonar transmit power (RMS)
5
CHIRP: 500W
Garmin ClearVü CHIRP: 500W
Sonar depth
6
701m (2,300 ft.) at 77kHz
Wireless frequency 2.4GHz @ 19.7dBm maximum
5x Models
Dimensions, chartplotter only (W x H x D) 188 x 122 x 61.5mm (7
3
/
8
x4
13
/
16
x2
7
/
16
in.)
Dimensions, on bail mount with sun cover (W x H x D) 212x143.3x100mm (8
3
/
8
x5
5
/
8
x3
15
/
16
in.)
Clearance to nearest obstruction behind chartplotter 57mm (2
1
/
4
in.)
Display size (W x H)
109x65.8mm (4
5
/
16
x2
9
/
16
in.)
127.3mm (5in.)diagonal
Weight 0.5kg (1.1lb.)
Max. power draw 8.4W
Typical current draw at 12Vdc (RMS) 600mA
Max. current draw at 12Vdc 700mA
Compass-safe distance 7.62cm (3in.)
3
The device withstands incidental exposure to water of up to 1m for up to 30min. For more information, go to www.garmin.com/waterrating.
4
Dependent upon the transducer.
5
Dependent upon the transducer rating and depth.
6
Dependent upon the transducer, water salinity, bottom type, and other water conditions.
