FLIGHT ID REPORTING
NOTE: If the Flight ID is required but the system is not configured for it, contact a Garmin-authorized service
center for configuration.
When the Flight ID must be entered before flight operation, the identifier is placed in the Timer/References
Window on the PFD. The Flight ID is not to exceed seven characters. No space is needed when entering Flight
ID. When a Flight ID contains a space, the system automatically removes it upon completion of Flight ID entry.
Entering a Flight ID:
1) Press the TMR/REF Softkey to display the Timer/References Window.
2) Press the FMS Knob to activate the selection cursor, if not already activated.
3) Turn the large FMS Knob to scroll down to the Flight ID.
4) Turn the small FMS Knob to enter the desired Flight ID.
5) Press the ENT Key to complete Flight ID entry.
If an error is made during Flight ID entry, pressing the CLR Key returns to the original Flight ID entry. While
entering a Flight ID, turning the FMS Knob counterclockwise moves the cursor back one space for each detent
of rotation. If an incorrect Flight ID is discovered after the unit begins operation, reenter the correct Flight ID
using the same procedure.
Figure 4-40 Timer/References Window, Entering Flight ID
Flight ID
PFD Entry
