The system displays the status of the radar antenna stabilization feature in the upper right corner of the
Weather Radar Page.
Radar Antenna
Stabilization Status
Description
STAB ON Antenna stabilization is selected on.
STAB OFF Antenna stabilization is selected off.
STAB INOP
The radar is not receiving pitch and roll information.
The antenna stabilization feature is inoperative.
Table 6-4 Antenna Stabilization Annunciations on the Weather Radar Page
If the unit fails, an annunciation as to the cause of the failure is shown as a banner in the center of the Weather
Radar Page.
Weather Radar
Page Center Banner
Annunciation
Description
BAD CONFIG The radar configuration is invalid. The radar should be serviced.
RDR FAULT The radar unit is reporting a fault. The radar should be serviced.
RADAR FAIL
The system is not receiving valid data from the radar unit. The system
should be serviced.
Table 6-5 Abnormal Radar Status Annunciations on the Weather Radar Page
