Garmin G950 - Page 35

190-00870-02 Rev. A
Garmin G950 Pilot’s Guide for the Pilatus PC-6
23
SYSTEM OVERVIEW
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICES INDEX
HSI FRMT Displays the softkeys for selecting the two HSI formats
360 HSI Displays HSI as a 360° compass rose
ARC HSI Displays HSI as a 140° viewable arc
BRG2 Cycles the Bearing 2 Information Window through NAV2 or GPS waypoint identifier and
GPS-derived distance information, and ADF/frequency.
ALT UNIT Displays softkeys for setting the altimeter and BARO settings to metric units
METERS When enabled, displays altimeter in meters
IN Press to display the BARO setting as inches of mercury
HPA Press to display the BARO setting as hectopacals
STD BARO Sets barometric pressure to 29.92 in Hg (1013 hPa if metric units are selected)
OBS Selects OBS mode on the CDI when navigating by GPS (only available with active leg)
CDI Cycles through GPS, VOR1, and VOR2 navigation modes on the CDI
DME Displays the DME Tuning Window, allowing tuning and selection of the DME (optional)
XPDR Displays transponder mode selection softkeys
STBY Selects standby mode (transponder does not reply to any interrogations)
ON Selects Mode A (transponder replies to interrogations)
ALT Selects Mode C – altitude reporting mode (transponder replies to identification and
altitude interrogations)
GND Manually selects Ground Mode, the transponder does not allow Mode A and Mode C
replies, but it does permit acquisition squitter and replies to discretely addressed Mode S
interrogations
VFR Automatically enters the VFR code (1200 in the U.S.A. only)
CODE Displays transponder code selection softkeys 0-7
0 — 7 Use numbers to enter code
BKSP Removes numbers entered, one at a time
IDENT Activates the Special Position Identification (SPI) pulse for 18 seconds, identifying the
transponder return on the ATC screen
TMR/REF Displays Timer/References Window
NRST Displays Nearest Airports Window
ALERTS Displays Alerts Window
Figure 1-16 Top Level PFD Softkeys
Press the BACK Softkey to return
to the top-level softkeys.
Press the BACK Softkey to return
to the top-level softkeys.
XPDR
STBY ON ALT VFR IDENT BACK ALERTSCODE
IDENT BACK
ALERTS
0 1 2 3 4 5 6 7 BKSP
BACK
Press the BACK Softkey to return
to the top-level softkeys.
DCLTR
DCLTR-2
DCLTR-3
DCLTR-1
TOPO
ALERTS
(if installed)
TERRAIN STRMSCP
OFF
INSET
STD BARO
BACK
ALERTS
WIND
HSI FMT
PFD
BRG
1
BRG2
Press the BACK Softkey to return
to the top-level softkeys.
ALT UNIT
DFLTS
Press the BRG1/BRG2
softkeys to display/remove
the Bearing Information
windows and cycle through
bearing sources:
- NAV1/NAV2
- GPS
GND
INSET XPDR IDENT TMR/REF NRST ALERTSOBSPFD CDI
Press the CDI Softkey to cycle through
navigation sources:
- GPS
- NAV1 (VOR/LOC)
- NAV2 (VOR/LOC)
DME
(optional)
DME
(optional)
SYN VIS
HPA BACK
ALERTS
METERS IN
BACK
ALERTS
OPTN1 OPTN2 OPTN3 OFF
BACK
ALERTS
360 HSI
ARC HSI
TRFC-1
TRFC-2
ALERTS
SYN TERR
HRZN HDG
PATHWAY
APTSIGNS
