1
Traffic Annunciation
2
Selected Heading
3
Wind Data
4
Inset Map
5
DME Information Window
6
Bearing Information Windows
7
Minimum Descent Altitude/Decision
Height
8
Flight Plan Window
9
Annunciation Window
10
Selected Course
11
Vertical Speed Required
12
Vertical Deviation Indicator (VDI)
13
Current VNV Target Altitude
14
Terrain Annunciation
Figure 2-2 Primary Flight Display (Additional Information)
