Garmin GI 275 Pilot's Guide190-02246-01 Rev. L
247
Additional Features
System
Overview
Flight
Instruments EIS Navigation
Hazard
Avoidance Autopilot IVSI
Additional
Features Appendices Index
Test In-Progress
Pointer
Rises to 50'
Ground Rad Alt Test
8.4 FLIGHT DATA LOGGING
The Flight Data Logging feature automatically connects and stores critical flight and engine
data to Garmin Pilot through Connext or to a USB device through Garmin's proprietary GSB
15. Data is recorded once each second while the power is applied to the system.
WIRELESS FLIGHT DATA LOGGING WITH CONNEXT
For registration and connection instructions, see the applicable sections in System Overview.
Wireless Flight Data Logging is enabled through Garmin Pilot and utilizes Connext. The
Flight Data Log is attached to your logbook entry and saved to flygarmin.com for future
analysis. While Garmin Pilot is running, the Flight Data Log is continuously streamed to
your Portable Electronic Device (PED). For the Flight Data Log to be available upon landing,
Garmin Pilot must be running for the duration of the flight.
EXPORTING FLIGHT DATA WITH A USB DRIVE
When a USB device is inserted into the optional GSB 15, flight data is automatically recorded
throughout the flight. Approximately 1,000 flight hours can be recorded for each 1GB of
available space on the USB device.
NOTE:
It is recommended to use a USB thumbdrive no larger than 32 GB. The USB
may not be detected for up to one minute after the GI 275 is powered On. If the USB
is inserted after one minute, detection of the USB and it's databases may take up to
15 seconds.
