55
Getting Started
Physical Specifi cations
Size: 1.2” x 2.7” x 6.2” (3.0cm x 6.9cm x 15.75cm)
Weight: 7.5 ozs (.21kg)
Display: 2.9" diagonal (6.0cm) high-contrast, 4-level gray
LCD with backlighting (180 x 240 pixels)
Case: Fully gasketed, fl oatable, high-impact plastic alloy,
waterproof to IEC 529-IPX-7
Temp. Range: 5°F to 158°F (-15°C to 70°C)
1
Performance
Battery Life: 16 Hours in Battery Saver Mode
Receiver: Differential-ready 12 parallel channel receiver
Acquisition Times: Approx. 15 seconds (warm start)
Approx. 45 seconds (cold start)
Approx. 5 minutes (First Time/AutoLocate™)
Update Rate: 1/second, continuous
GPS Accuracy: *< 15 meters (49 feet) RMS 95% typical
DGPS (USCG) Accuracy: 3-5 meters (10-16 ft), 95% typical
DGPS (WAAS) Accuracy: 3 meters (10ft) 95% typical with DGPS corrections
Compass Accuracy: ± 5 degrees
2
Velocity Accuracy: 0.1 knot RMS steady state
Dynamics: 6g's
* Subject to accuracy degradation to 100m 2DRMS under the U.S. DOD-imposed Selective Availability Program.
Power
Batteries: Two 1.5-volt AA batteries
1
Source: 8-35V DC
Fuse: AGC/3AG - 2.0 Amp
1
The temperature rating for the GPSMAP 76S may exceed the usable range of some batteries. Alkaline batteries can rupture at
high temperatures. Alkaline batteries lose a signifi cant amount of their capacity as temperature decreases. Use lithium batteries
when operating the GPSMAP 76S in below-freezing conditions. Extensive use of screen backlighting will signifi cantly reduce
battery life.
2
Subject to proper user calibration
Appendix A
Specifi cations
190-00249-00_0C.indd 55 5/7/2003, 9:55:00 AM
