System at a Glance
190-02327-03 Rev. C Pilot’s Guide 1-15
Page Navigation Labels
A locater bar works in conjunction with the outer control knob, providing quick
access to the indicated page. Selectable page options are dependent upon
configuration.
Shortcut Labels Active Page
Turning the outer knob clockwise
or counter-clockwise moves the
locater through available page
options.
A cyan background and border
indicate active page and knob
focus. Directional arrows show
when more options are available.
Locater More Page Options
Customizable Page Slots
GTN Xi series navigators allow
you to customize up to seven
slots on the locater bar.
First and last slots are dedicated
page shortcuts. Depending on
unit type, slot 1 may open Map
1
or Default Navigation features
2
.
Slot 9, the last slot, opens the
Nearest Airport menu.
1
GTN 750Xi Series only.
2
GTN 650Xi Series only.
For more about customizable page
slots, read Page Shortcuts in section 2.
