structure.
When pinpointing, the Upper Scale on the LCD Screen
indicates signal strength. When the greatest number of
LCD segments (increasing left to right on the scale) is
shown, the center of the searchcoil is directly over the
target with the depth of a coin-sized target shown on the
depth scale.
4. MODE options:
• CUSTOM Mode - This Mode can be
programmed solely by the operator. The
ACE 250 is factory preset with the CUSTOM
Mode set the same as the COINS Mode. By
using the DISCRIM and ELIM push buttons, an
operator can modify the Notch Discrimination
settings to individual specifications, which will
be retained in the CUSTOM Mode when the
ACE is turned OFF.
21
2. ELIM Pushbutton - Press the ELIM (Eliminate)
pushbutton to eliminate or activate the LCD cursor
located on the Lower Scale, directly below the Target ID
cursor.
The ELIM function can be used to modify each Mode’s
discrimination pattern. For example, when an unwanted
target is located while hunting press the ELIM button to
create a Notch (delete the cursor) to eliminate that
specific target.
All Notch Discrimination modifications made while in the
CUSTOM mode will be retained when the detector is
turned OFF. However, all changes made to the Notch
Discrimination scale while in the ALL-METAL, JEWELRY,
RELICS and COINS modes will return to the factory
settings when the detector is turned OFF.
3. PINPOINT Push Button - Press and hold the
Pinpoint pushbutton to determine the exact location of a
target that is still hidden in the ground, wall or other
20
